IT-9927G-HD-5MP
(English) 5.0 Megapixel HD Network Ultra Starlight Box Camera
Description
Features
- H.265/ H.264/ M-JPEG, Support Multiple Code Stream
- Built-in Auto Double Filter Switching Mechanism, True Day/Night
- Support ONVIF, 3D-MCTF DNR and the ROI Compression Interested Area
- Support Corridor Mode, Adapt to the Special Area Show in Long and Narrow Corridor
- The Power Interface using Error Prevention Design, Avoid Mistaken Insertion or Reverse Damage to the Camera Circuit
- Support HDMI Output, DC12V/AC24V/POE
(English)
TECHNICAL SPECIFICATIONS
| Model | Model No. | IT-9927G-HD-5MP |
|---|---|---|
| Type | 5.0 Megapixel HD Network Ultra-Low Light Box Camera | |
| Camera | Sensor | 1/1.8"Sony CMOS |
| Min. Illumination | Color 0.005Lux @F1.2; B/W0.0005Lux @F1.2 | |
| Electronic Shutter | 1 / 25 ~ 1 / 10000 | |
| Lens Interface | C/CS | |
| DNR | 3D DNR | |
| S/N Ratio | ≥52db | |
| Aperture Type | DC Drive, Support Auto/ Manual/ Fixed Lens | |
| WDR | ≥120db | |
| BLC | Support | |
| Images | Video Compression | H.265/H.264/MJPEG, Support Frame Rate Adjustable |
| Code Stream | VBR/CBR/LBR | |
| Frame Rate | 2592*1944, 1-25(30)FPS; 2560*1920, 1-25(30) FPS; 2048*1536 , 1-25(30) FPS; 1920*1080, 1-25(30) FPS | |
| Image Setting | Adjustable Image Format, Standard, Code Rate, Brightness, Contrast, Saturation, Sharpness, White Balance, Image Flip, and Mirror (Passage Mode) 4A Auto Control, OSD Information Overlay; Image Flip | |
| Intelligent Features | Intelligent Code Stream, Video Mask, Out-of-focus Detection, Intelligent Switch Control | |
| Protocol | IPv4, TCP/IP, UDP, HTTP, DHCP, RTP/RTCP/RTSP, FTP, UPnP, DDNS, NTP, IGMP, ICMP | |
| Compatible | Support ONVIF | |
| Interfaces | Audio Interface | 3.5mm Microphone/ Line in, External Active Microphone or Line Input |
| Communication Interface | 1* RJ45 10Base-T/100Base-TX | |
| Alarm Input / Output | 1CH Input, 1CH Output | |
| Mobile Surveillance | Support | |
| RS485 | Support | |
| CVBS/BNC | Support | |
| TF card | Support | |
| General | Working Conditions | -20°C ~ 60°C, 20-80% RH ( non-condensing ) |
| Power Supply | POE/DC12V/AC24V ±10% | |
| Dimensions (mm) | 152 (L)x81(W)x54(H)mm (Without Lens) | |
| Weight (with Package) | 820g |
